Multi-Layer Sintered Metal Fiber Felt with 7600 Bubble Point and 35L/dm2.min Air Permeability
| Place of Origin | Yiyang,China |
|---|---|
| Brand Name | huitong |
| Certification | SGS IOS9001 |
| Model Number | HT-MP5 |
| Minimum Order Quantity | 1m2 |
| Price | Negotiable |
| Packaging Details | paper carton or customized package |
| Delivery Time | depends on quantity |
| Payment Terms | T/T,Western Union,MoneyGram,,L/C |
| Supply Ability | 50000m2 per month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Diameter | 5um | Weight | 700g/m2 |
|---|---|---|---|
| Thickness | 0.43mm | Porosity | 80% |
| Bubble Pressure | 7600Pa | Air Permeability | 35L/dm2.min |
| Highlight | 0.43mm Thickness Sintered Metal Fiber Felt,Multi Layer Sintered Metal Fiber Felt,80% Porosity sintered fiber felt |
||
Product Description
0.43mm Thickness 80% Porosity 7600 Bubble Point Multi-Layer Sintered Metal Fiber Felt
Product Description
- Excellent strength and durability
- Multi-layer structure for enhanced performance
- Superior dirt holding capacity
- Uniform mesh structure with consistent pore size
- High pressure and temperature resistance
- Excellent corrosion resistance
- Washable and reusable multiple times
- Low pressure loss with high flow rate
Technical Specifications
| Diameter (µm) | Thickness (mm) | Porosity (%) | Bubble Point (Pa) | Air Permeability (L/dm².min) |
|---|---|---|---|---|
| 3 | 0.37 | 67 | 13000 | 13 |
| 5 | 0.43 | 80 | 7600 | 35 |
| 7 | 0.36 | 74 | 5050 | 60 |
| 10 | 0.34 | 78 | 3700 | 85 |
| 15 | 0.38 | 80 | 2470 | 170 |
| 20 | 0.51 | 82 | 1850 | 265 |
| 25 | 0.62 | 79 | 1480 | 325 |
| 30 | 0.62 | 79 | 1235 | 450 |
| 40 | 0.63 | 76 | 900 | 620 |
| 60 | 0.57 | 83 | 600 | 1350 |
| 86 | 1.00 | 84 | 480 | 1470 |
| 80 | 1.00 | 85 | 450 | 1510 |
| 90 | 1.20 | 88 | 410 | 1740 |
| 100 | 1.30 | 89 | 360 | 2000 |
Applications
- Filtration for chemical fiber, film, and viscose industries
- High-temperature flue gas dust precipitators
- Petroleum and petrochemical applications
- Fuel and hydraulic oil filtration systems
