Blue 304 Stainless Steel Conductive Wire Abrasion Resistant

Blue 304 Stainless Steel Conductive Wire Abrasion Resistant

  • High Light

    304 stainless steel conductive wire

    ,

    abrasion resistant stainless steel conductive wire

    ,

    blue stainless steel conductive wire

  • Material
    316L,304
  • Usage
    Heating Wire
  • Application
    Heating Blanket
  • Coating
    MFA
  • Color
    Blue
  • Length
    Customize Length
  • Place of Origin
    Yiyang,China
  • Brand Name
    huitong
  • Certification
    ROHS
  • Model Number
    HT-CH60-T16
  • Minimum Order Quantity
    10kg
  • Price
    Negotiable
  • Delivery Time
    depends on quantity
  • Payment Terms
    T/T
  • Supply Ability
    10tons per months

Blue 304 Stainless Steel Conductive Wire Abrasion Resistant

stainless steel conductive wire for automible heating system





【Description】
The ultra-fine metal fiber composite wire is made of a single or multi-strand microfiber wire twisted to form a flexible wire.
Features:
* Good electrical conductivity
* High strength, high elastic modulus
* Abrasion resistance, corrosion resistance
* Excellent thermal stability in an oxidizing atmosphere

【Application】
Due to electrostatic attraction, the effect of static electricity on the printer is very large (seriously it may damage the motherboard and the nozzle), so it’s necessary to eliminate the effect of static electricity on the printing process. The excellent electrical conductivity and stable physicochemical properties of the ultra-fine metal fiber composite wire greatly enhance its static elimination in the plastics and paper industries. Various specifications of electrostatic brushes produced by our ultra-fine metal fiber composite wire are suitable for medium and high speed printing machinery, slitting machinery, bag making machinery, laminating machine, etc.

【Parameters】
Type Weight/Meter(g) Break force(N) Elongation(%) Average Electricity Resistance(Ω)
14μm×90×1 0.12 25 1.10% 61
12μm×90×2 0.17 44 1.10% 42
12μm×100×1 0.095 24 1.10% 59
12μm×100×2 0.19 41 1.10% 38
12μm×100×3 0.28 69 1.10% 22
12μm×275×1 0.26 59 1.10% 27
12μm×275×2 0.54 75 1.10% 14
12μm×275×3 0.78 125 1.10% 9
12μm×275×4 1.05 130 1.10% 7
12μm×275×5 1.3 160 1.10% 5
12μm×275×6 1.5 180 1.10% 4
8μm×1000×1 0.42 69 1.10% 16
8μm×1000×2 0.85 108 1.10% 8
12μm×1000×1 0.95 100 1.10% 7
12μm×1000×2 1.9 340 1.10% 4

【Other Application】
The ultrafine metal fiber composite wire has excellent electrical conductivity, high strength, high elastic modulus, abrasion resistance, corrosion resistance and excellent thermal stability in an oxidizing atmosphere, and can be widely applied to an antistatic brush and high temperature sewing thread, radio frequency identification, etc.
