316L 310S 304 1um 3um 5um Corrosion Resistant Sintered Metal Fiber - Conductive Stainless Steel Fiber For Industrial Applications
Product Details
| Materials | 316L,310S,304 | Fiber Diameter | Regular 4.5um/6.5um/7.3um/8um/12um/22um |
|---|---|---|---|
| Filaments | Regular 1000f/2000f/3000f/4000f/6000f | Strength(cN) | ≥18cN |
| Product Name | Sintered Metal Fiber | Certification | ISO9001/ISO14001/ISO45001/ROHS/Reach |
| Highlight | 2um sintered metal fiber,302SS sintered metal fiber,302 stainless steel conductive fiber |
||
Product Description
1-100μm Conductive Metal Fibers
Premium stainless steel fibers including 316L, 304, 310S, Fecral, Nickel, Titanium, and Hastelloy variants with diameters ranging from 1-100μm.
Product Description
Our stainless steel fibers are manufactured using advanced bundle drawing technology, producing micron-level diameter wires with a metallic stainless steel appearance and bright surface finish. These fibers retain the essential properties of stainless steel while gaining enhanced characteristics due to their microscopic scale.
Key Characteristics
- Maintains excellent electrical conductivity and thermal properties
- Superior corrosion resistance inherent to stainless steel
- Enhanced softness and flexibility comparable to chemical fibers
- Large surface area-to-volume ratio for improved performance
- Ideal substrate material for various stainless steel fiber products
Applications
Versatile applications across multiple industries including textiles, filtration systems, metallurgy, paper manufacturing, and various industrial, civilian, and applications.
Technical Specifications
| Diameter (μm) | Filament Count | Strength (cN) | Elongation Rate (%) |
|---|---|---|---|
| 4.5 | 10500 | ≥2.0 | ≥0.7 |
| 6.5 | 3500-7000 | ≥4.5 | ≥1.0 |
| ≥3.0 | ≥0.8 | ||
| 7.3 | 3500-7000 | ≥5.5 | ≥1.0 |
| ≥4.0 | ≥0.9 | ||
| 8 | 2250-4500 | ≥7.0 | ≥1.05 |
| ≥4.0 | ≥0.85 | ||
| 12 | 2000-4000 | ≥18 | ≥1.1 |
| ≥13.5 | ≥0.9 | ||
| 22 | 500-10000 | ≥50 | ≥1.25 |
