SUS316L Stainless Steel Fiber Reliable Protection Against Electrostatic Charge
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Material | SUS316L | Properties | Anti Static |
|---|---|---|---|
| MOQ | 10kg | Temperature | 500degree |
| Product Name | Stainless Steel Conductive Fiber | Certification | SGS |
| High Light | SUS316L Stainless Steel Fiber,Conductive SUS316L Stainless Steel Fiber,SUS316L Stainless Steel Conductive Fiber |
||
Product Description
SUS316L Stainless Steel Fiber--Reliable Protection Against Electrostatic Charge
Stainless steel fibers are manufactured using the bundle drawing process, in which stainless steel wires are bundled into a tube and drawn through a die to produce a fine fiber with a diameter ranging from 1 to 40 microns (up to 60 times thinner than human hair).
Stainless steel fibers exhibit all the common features of the metal, yet are flexible enough to be transformed into knitted, braided, woven, or nonwoven metal fiber and fabric products. They can also be spun and twisted with other fibers such as wool, nylon, cotton, and synthetic blends to produce a variety of textile materials. Our common fiber types include 316L, 302, 304, 430, 434, Hastelloy and Inconel.
Stainless steel fibers possess many beneficial properties, such as good electric and heat conductivity, high corrosion and thermal resistance (400-600°C), and excellent EMI and ESD shielding capabilities.
These factors allow stainless steel fibers to be used throughout numerous consumer and industrial applications in diverse fields, including the textile, electrical, filtration, petrochemical, metallurgy, environment protection, papermaking, military, and aerospace and aviation industries.
Main technical parameters as follows:
| Diameter(μm) | Filaments(f) | Strength(cN) | Elongation(%) |
Weight/meter(g/m) |
| 4.5 | 12000 | ≥2.0 | ≥0.7 | 1.40～1.64 |
| 6.5 | 6000 | ≥4.5 | ≥1.0 | 1.56～1.70 |
| 7.3 | 6000 | ≥5.5 | ≥1.0 | 1.98～2.14 |
| 6000 | ≥4.0 | ≥0.8 | 1.92～2.20 | |
| 8 | 6000 | ≥7 | ≥1.05 | 2.34～2.57 |
| ≥4.0 | ≥0.85 | 2.26～2.62 | ||
| 12 | 2000 | ≥18 | ≥1.1 | 1.82～1.98 |
| ≥13.5 | ≥0.9 | 1.76～2.04 | ||
| 22 | 1000 | ≥50 | ≥1.25 | 3.06～3.3 |
Annotate:
1)The diameter of the fiber can be produced between 1 and 100 micron according to the customer’s request.
2)The fiber’s filaments and breaking strength of single fiber can be controlled by the customer’s request.
3)The fiber’s room temperature resistance will change along with the stainless steel state.
Main Application:
1 Pure stainless steel fiber fabric
2 Blended spun stainless steel fiber Fabrics
3 Metal fiber sintered felt
4 Conductive plastics for electromagnetic shielding and anti-static,anti-counterfeit and anti-static paper
5 Fiber reinforced materials
6 anti-static brush,anti-static wrist brand etc
7 High Temperature heating body
8 High temperature cushion mould,high temperature conveyor be
